Since its foundation, HSG has been a leader in Business Rule Management Systems Training and Consulting services by way of the Blaze Advisor Rule Engine.  Over the years we have provided such services to many of the worlds largest corporations and government institutions whose respective backgrounds include credit card processing, banking, insurance, health and medicine and more, much more.  Such training and consulting services have included:

Create a wrapper object model in either Java, .NET or XML

Identify and catalog business rules

Develop a rule architecture within Blaze Advisor that isolates rule repositories as they relate to functionality and corporate policies

Configure, develop and implement a variety of interfaces to the rule engine from disparate systems ranging from mainframe applications written in Cobol to UNIX/Windows applications using Enterprise Java Beans, Windows Services, Web Services, Fat Clients, Java Messaging Services and Web Applications.

Review and update code to boost efficiency either by way of

    Removing functions calls within conditional statements

    Ensuring that database calls are essential or can be rearchitected in some other manner

    Employing the rete algorithm where necessary

    Paring down extensively large class models

    Deploying such appliations in multi-threaded systems

·         ...

Call us if you:

    are in need of Blaze Advisor Expertise
    are developing SMEs in Blaze
    want to speak directly with an expert (no placement agencies)
    want an affordable alternative to FICO
    want to work with an industry leader

Sage wisdom states that there are two sides to every coin. This timeless wisdom will be borne out in spades with Windows 8/RT. Let's get into the dark side first.

If your users are veterans of Windows it is safe bet they are going to take one look at Windows 8 and scream blasphemy. Users whose brains are geared towards visual learning will undoubtedly yell the loudest and longest.

There's a good reason for this. Mick Jagger brought his band to the Redmond campus, performing live "Start Me Up" in the summer of 1995 (it was a great show). This heralded in the abandonment of program icons sitting on the desktop and introduced the now legacy Start button.

Ending the life of the 17-year-old start button is not going to go well with some users.

I will begin our blog on Java Tutorial with an incredibly important aspect of java development:  memory management.  The importance of this topic should not be minimized as an application's performance and footprint size are at stake.

From the outset, the Java Virtual Machine (JVM) manages memory via a mechanism known as Garbage Collection (GC).  The Garbage collector

• Manages the heap memory.   All obects are stored on the heap; therefore, all objects are managed.  The keyword, new, allocates the requisite memory to instantiate an object and places the newly allocated memory on the heap.  This object is marked as live until it is no longer being reference.
• Deallocates or reclaims those objects that are no longer being referened.
• Traditionally, employs a Mark and Sweep algorithm.  In the mark phase, the collector identifies which objects are still alive.  The sweep phase identifies objects that are no longer alive.
• Deallocates the memory of objects that are not marked as live.
• Is automatically run by the JVM and not explicitely called by the Java developer.  Unlike languages such as C++, the Java developer has no explict control over memory management.
• Does not manage the stack.  Local primitive types and local object references are not managed by the GC.

So if the Java developer has no control over memory management, why even worry about the GC?  It turns out that memory management is an integral part of an application's performance, all things being equal.  The more memory that is required for the application to run, the greater the likelihood that computational efficiency suffers. To that end, the developer has to take into account the amount of memory being allocated when writing code.  This translates into the amount of heap memory being consumed.

Memory is split into two types:  stack and heap.  Stack memory is memory set aside for a thread of execution e.g. a function.  When a function is called, a block of memory is reserved for those variables local to the function, provided that they are either a type of Java primitive or an object reference.  Upon runtime completion of the function call, the reserved memory block is now available for the next thread of execution.  Heap memory, on the otherhand, is dynamically allocated.  That is, there is no set pattern for allocating or deallocating this memory.  Therefore, keeping track or managing this type of memory is a complicated process. In Java, such memory is allocated when instantiating an object:

String s = new String();  // new operator being employed
String m = "A String";    /* object instantiated by the JVM and then being set to a value.  The JVM
calls the new operator */

A business rule is the basic unit of rule processing in a Business Rule Management System (BRMS) and, as such, requires a fundamental understanding. Rules consist of a set of actions and a set of conditions whereby actions are the consequences of each condition statement being satisfied or true. With rare exception, conditions test the property values of objects taken from an object model which itself is gleaned from a Data Dictionary and UML diagrams. See my article on Data Dictionaries for a better understanding on this subject matter.

A simple rule takes the form:

if condition(s)

then actions.

An alternative form includes an else statement where alternate actions are executed in the event that the conditions in the if statement are not satisfied:

if condition(s)

then actions

else alternate_actions

It is not considered a best prectice to write rules via nested if-then-else statements as they tend to be difficult to understand, hard to maintain and even harder to extend as the depth of these statements increases; in other words, adding if statements within a then clause makes it especially hard to determine which if statement was executed when looking at a bucket of rules. Moreoever, how can we determine whether the if or the else statement was satisfied without having to read the rule itself. Rules such as these are often organized into simple rule statements and provided with a name so that when reviewing rule execution logs one can determine which rule fired and not worry about whether the if or else statement was satisfied. Another limitation of this type of rule processing is that it does not take full advantage of rule inferencing and may have a negative performance impact on the Rete engine execution. Take a class with HSG and find out why.

Rule Conditions
